Can you rebuild this microstructure?

Vertical stripes have identical rows. Their mean row already contains the complete pattern, so no components are needed. Rotation gives rows with different colors, which introduces variation. A two-color checkerboard has a single independent centered row pattern and needs one component when both row types occur. A uniform pattern also needs zero components.

Clusters and random arrangements generally have more independent row patterns. A centered table with N rows has rank at most N − 1, so the game never needs more than that many components for numerical reconstruction. This is a bound from the data arrangement, not a rule that all random images require the maximum.

Each integer in the image is a color label, not a composition or brightness. I use VIBGYOR plus white. The palette affects the display, but does not affect the one-hot PCA calculation. Rows and columns count pixels; there is no physical length calibration.

PALETTE = ['#8b5cf6', '#4f46e5', '#3b82f6', '#22c55e',
           '#facc15', '#fb923c', '#ef4444', '#ffffff']

The seed determines the random-number sequence. The same size, color count, pattern, patch width and seed give the same labels in Python and the browser. Clustered patterns assign each pixel the color of its nearest seed point. These are invented geometrical patterns, not phase-field simulation results. Patch width is measured in pixels. In a checkerboard it sets block width; in stripes it sets band width. For random and uniform patterns it has no effect.

def random_numbers(seed):
    state = int(seed) & 0xffffffff
    while True:
        state = (1664525 * state + 1013904223) & 0xffffffff
        yield state / 4294967296


def make_pattern(size, colors, kind, width, seed):
    random = random_numbers(seed)
    labels = np.zeros((size, size), dtype=int)
    offset = int(next(random) * colors)
    centers = []
    if kind == 'clustered':
        count = max(colors, int(np.floor(size * size / (width * width) + 0.5)))
        for i in range(count):
            centers.append((next(random) * size, next(random) * size, i % colors))
    for row in range(size):
        for column in range(size):
            label = offset
            if kind == 'random':
                label = int(next(random) * colors)
            elif kind == 'horizontal':
                label = (row // width + offset) % colors
            elif kind == 'vertical':
                label = (column // width + offset) % colors
            elif kind == 'diagonal':
                label = ((row + column) // width + offset) % colors
            elif kind == 'checkerboard':
                label = 0 if (row // width + column // width) % 2 == 0 else colors - 1
            elif kind == 'clustered':
                nearest = float('inf')
                for center_row, center_column, color in centers:
                    distance = (row - center_row)**2 + (column - center_column)**2
                    if distance < nearest:
                        nearest = distance
                        label = color
            labels[row, column] = label
    return labels

One-hot encoding uses one entry per color. For example, with three colors, color 0 is [1, 0, 0] and color 2 is [0, 0, 1]. np.eye creates this table. Indexing it with labels gives an array of shape (size, size, colors). reshape puts each image row into one data row, keeping the color entries of each column together. At size 16 and eight colors, X has shape (16, 128). The mean is calculated down rows, separately for each feature.

def encode_rows(labels, colors):
    size = labels.shape[0]
    return np.eye(colors)[labels].reshape(size, size * colors)

The data observations here are image rows, not a collection of complete images. Centering subtracts the mean row. Vt contains the principal directions as rows; scores tells me how much each observation uses each direction. @ is matrix multiplication; :count keeps the first count entries or directions. I add the mean back when reconstructing. Zero components therefore gives the mean row repeated down the image. The centered rank cannot exceed size minus one. RMSE is calculated over all one-hot entries, with no physical units.

def analyze_pattern(labels, colors):
    X = encode_rows(labels, colors)
    mean_row = X.mean(axis=0)
    centered = X - mean_row
    U, strengths, Vt = np.linalg.svd(centered, full_matrices=False)
    scores = centered @ Vt.T
    total_variation = np.sum(strengths**2)
    states = []
    size = len(labels)
    for count in range(size):
        rebuilt = mean_row + scores[:, :count] @ Vt[:count]
        weights = rebuilt.reshape(size, size, colors)
        recovered = weights.argmax(axis=2)
        rmse = np.sqrt(np.mean((X - rebuilt)**2))
        correct = int(np.sum(recovered == labels))
        fraction = None if total_variation < 1e-12 else np.sum(strengths[:count]**2) / total_variation
        states.append({'count': count, 'rmse': float(rmse), 'correct': correct,
                       'fraction': fraction, 'labels': recovered, 'weights': weights})
    return {'labels': labels, 'states': states,
            'exact': next(s['count'] for s in states if s['rmse'] < 1e-8),
            'phase': next(s['count'] for s in states if s['correct'] == size * size)}

The largest reconstructed weight chooses the displayed color. argmax selects the first color when weights tie exactly. These weights are not probabilities: some can be negative or greater than one. Recovering every color label does not require every weight to be exactly 0 or 1. The browser uses a Jacobi eigensolver and this notebook uses NumPy SVD. When principal variances tie, valid intermediate component directions can differ, as can the smallest count that recovers every label. Numerical rank and reconstruction error agree within rounding. The browser game refers to its own calculated directions.

def run_example():
    size = 16
    colors = 8
    kind = 'clustered'
    width = 3
    seed = 42
    labels = make_pattern(size, colors, kind, width, seed)
    result = analyze_pattern(labels, colors)
    for state in result['states']:
        print(f"Components: {state['count']:2d}, RMSE: {state['rmse']:.6f}, "
              f"correct colors: {state['correct']}/{size * size}")
    print('Minimum for numerical reconstruction:', result['exact'])
    print('Minimum for pixel colors with this NumPy basis:', result['phase'])
    retained = 4
    colormap = ListedColormap(PALETTE[:colors - 1] + [PALETTE[-1]])
    fig, axes = plt.subplots(1, 2, figsize=(8, 4))
    axes[0].imshow(labels, cmap=colormap, vmin=0, vmax=colors - 1, interpolation='nearest')
    axes[1].imshow(result['states'][retained]['labels'], cmap=colormap,
                   vmin=0, vmax=colors - 1, interpolation='nearest')
    axes[0].set_title('Original pattern')
    axes[1].set_title(f'{retained}-component reconstruction')
    for ax in axes:
        ax.set_xlabel('Column index')
        ax.set_ylabel('Row index')
    plt.tight_layout()
    plt.show()
    return result

I compare each new RMSE with the preceding one and check full numerical recovery. Vertical stripes have identical rows, so the saved mean row already reproduces them. A two-color checkerboard has one independent centered row pattern. These are checks of this representation. They do not establish that a real microstructure has only one physical mechanism.

def check_examples():
    for kind in ['uniform', 'vertical', 'horizontal', 'checkerboard', 'diagonal', 'clustered', 'random']:
        result = analyze_pattern(make_pattern(12, 8, kind, 2, 42), 8)
        errors = [state['rmse'] for state in result['states']]
        assert errors[-1] < 1e-8
        assert all(b <= a + 1e-12 for a, b in zip(errors, errors[1:]))
        if kind in ['uniform', 'vertical']:
            assert result['exact'] == 0
        if kind == 'checkerboard':
            assert result['exact'] == 1
    print('All pattern checks passed.')


if __name__ == '__main__':
    run_example()
    check_examples()
